Product Details:
Brand Name: Sintec Optronics
Model Number: STC001
Payment & Shipping Terms:
Delivery Time: Stock
Payment Terms: T/T via bank

Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter

Description
Laser Output Power: 500W/1000W/2000/3000W Max Cutting Speed: 18m/min
Cooling System: Water Cooling Drive Mode: Servo Motor
Power Supply: 380V/50HZ Max Cutting Thickness: 3-6mm According To Material
Application: Cutting For Metal Sheet
Highlight:

Fiber Metal Sheet Laser Cutter

,

6KW CNC Laser Cutter Machine

,

Fiber Laser Cutter For Metal

IPG Raycus Fiber Laser Cutting Machine for Metal Sheet Factory Price

What are the Specifications and Features?

Overview



The fiber laser cutting machine 1000W has a high-quality beam, high reliability, good optical mode, high top power, smooth incision, good perpendicularity,

it is a special cutting machine, which is suitable for stainless steel, carbon steel, Copper, and Aluminum, and  to cut and punch, the cutting speed and incision are both high levels,

CYPCUT program can process any graphics and text, running stably, with good processing quality, high efficiency, good precision, easy operation, and convenient maintenance.



Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter 0





Specification



Laser output power 500W/1000W/2000/3000W
Laser wavelength 1070 nm
Laser medium Glass fiber with the rare-earth element
Max cutting speed 18m/min
Max cutting thickness 3-6mm according to material
Output energy regulating 10%~100%
Input electric power for laser ≤2KW
Type of cooling Water cooling
Drive mode Imported servo motor
Transmission mode Imported high precision Rack and Pinion
Max-range for cutting 3000mm×1500 mm/ 2500x1300mm
Power supply 380V/50HZ
Contour dimension 4270mm×2420 mm×1750 mm



Detailed description of all parts:

Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter 1

Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter 2

Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter 3

Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter 4

Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter 5



Advantage

1. Excellent beam quality: Smaller focus diameter and high work efficiency, high quality.

2. High cutting speed: Cutting speed is more than 12m/min

3. Stable running: Adopting the top world import fiber lasers, stable performance, key parts can reach 100, 000 hours;

4. High efficiency for photoelectric conversion: Compare with CO2 laser cutting machines, fiber laser cutting machines have three times photoelectric conversion efficiency.





Applications



It is used widely in advertising signs production, sheet metal structures, production of high and low-voltage electrical cabinets, textile machinery parts,

kitchen, auto, machinery, metal technics, saw, electrical parts, glasses, spring, PCB, electrical kettle, medical microelectronics, hardware, tools, etc.



Cutting Thickness table:



Material / Laser Power 500W 750W 1000W 1200W 2000W 3000W 4000W
Carbon Steel 6mm 8mm 10mm 14mm 16mm 20mm 22mm
Stainless Steel 3mm 4mm 5mm 6mm 8mm 10mm 12mm
Aluminum 1mm 3mm 4mm 5mm 6mm 8mm 10mm
Brass 1mm 2mm 4mm 4mm 6mm 8mm 8mm
Copper 1mm 2mm 3mm 3mm 4mm 5mm 6mm
Galvanized Steel 1mm 2mm 4mm 5mm 6mm 8mm 10mm



Cutting Samples

Laser Cutter Machine/500W 1000W 2000KW 3000W Fiber Metal Sheet Laser Cutter 6
