Low Power / Medium Power / High Sensitivity Laser Power Energy Meter

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter
Low Power / Medium Power / High Sensitivity Laser Power Energy Meter Low Power / Medium Power / High Sensitivity Laser Power Energy Meter Low Power / Medium Power / High Sensitivity Laser Power Energy Meter Low Power / Medium Power / High Sensitivity Laser Power Energy Meter Low Power / Medium Power / High Sensitivity Laser Power Energy Meter

Large Image :  Low Power / Medium Power / High Sensitivity Laser Power Energy Meter

Product Details:
Brand Name: Sintec Optronics
Model Number: SHY Series
Payment & Shipping Terms:
Minimum Order Quantity: 1
Delivery Time: Stock
Payment Terms: T/T via bank
Contact Now

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter

Description
Highlight:

Laser Power Energy Meter

,

Laser Power Meter

,

Lasers Energy Meters

Low-power/Medium-power/High Sensitivity Laser Power Meters, Laser Energy Meters



SHY series laser power meters, with the core component of high-quality calorimetric probe as the starting point, are simple & easy to use, reliable via using the latest embedded technology design. This laser power meter with display head has a variety of specific probes to choose from, which is suitable for handheld measurement, but also suitable for online monitor of the running machines.

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 0

Probe:

  • Fast response (10W probe with display head 0-95% response time 1.5 seconds)
  • Wavelength range: 0.19-1um, NIST tracer correction, compact shape, built-in fan, and no external power supply optimized heat sink design
  • High load power (10W probe: continuous 10W, intermittent maximum 20W)
  • Square probe, easy to integrate, can be easily installed into the equipment
  • Optical fittings mounting thread, omnidirectional adjustment support

Display head:

  • High resolution color TFT screen, two-stage backlight, USB port for charging power, and data upload
  • Convenient after sale, short cycle
  • Provide standard RS232 interface output lithium rechargeable battery, power failure working time >=14 hours all metal body, light weight
  • No need to adjust zero (using suspension self-stabilizing zero circuit)
  • Automatic range switching (AutoScale)
  • User - defined correction coefficient, patent adjustable Ac algorithm toaster protection
  • Ideal partner for laser research and development (real-time monitoring power, abnormal laser shutdown)
  • Non-volatile data recording, up to 10,000 points high precision 12bit real-time
  • Power waveform diagram display, time adjustable
  • Easy to use menu and shortcut key mechanism
  • Anti-electromagnetic interference

Applications:

  • Portable equipment on-line measurement
  • Laser marking, cutting, drilling
  • Welding, light control, machine testing
  • Power monitoring control compensation

1. Low-power Laser Power Meter

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 1

Model number SHY-TP2-HP-19 SHY-TP10-HP-25 SHY-TP10-HP-19 SHY-TP50-HP-19 SHY-TP100-HP-19 SHY-TP150-HP-19
Maximum average power 2W 10W 10W 50W 100W 150W
Minimum power 1mW 20mW 20mW 50mW 100mW 100mW
Power resolution 1mW 0.001W 0.001W 0.01W 0.01W 0.01W
Noise Equivalent power(NEP) 100uW 4mW 1mW 20mW 0.1W 0.1W
Response time 1sec 1.5sec 1sec 1.5sec 2sec 2.5sec
Power calibration uncertainty ±3% ±2% ±3% ±3% ±3% ±3%
Power linearity* ±1% ±1.5% ±1% ±1.5% ±1% ±1.5%
Aperture 19mm 25mm 19mm 19mm 19mm 19mm
Type HPB HPB HPB HPB HPB HPB
Absorption spectrum 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um
Spectral range 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um
Maximum power density** 11kW/cm2 @2W 11kW/cm2 @10w 15kW/cm² @10W 11kW/cm² @40W 11kW/cm² @40W 11kW/cm² @40W
Cooling Air cooling Air cooling Air cooling Air cooling Air cooling Air cooling
Weight 0.2kg 0.2kg 1.0kg 1.5kg 1.0kg 1.5kg
Dimension 60x60x20mm 60x60x20mm 65x65x35mm 65x65x35mm 65x65x70mm 65x65x72mm
Connector length 2.5m 2.5m 2.5m 2.5m 2.5m 2.5m
  • * The detector is centrally illuminated at 50% of the effective surface.
  • ** The damage threshold also depends on the power level.

2. Medium-power Laser Power Meter

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 2

Model number SHY-TP200-HP-25 SHY-TP300-HP-25 SHY-TP500-HP-25 SHY-TP1000-HP-25
Maximum average power 200W 300W 500W 1000W
Minimum power 0.1W 0.3W 0.5W 1W
Power resolution 0.01W 0.1W 0.1W 0.1W
Energy range 100mJ-300J 100mJ-300J
Response time 1.8sec 2sec 5sec 5sec
Power calibration uncertainty ±3% ±3% ±3% ±3%
Power linearity* ±1% ±1.5% ±1% ±1.5%
Aperture 25mm 25mm 25mm 25mm
Type HPB HPB HPB HPB
Absorption spectrum 0.19-11um 0.19-11um 0.19-11um 0.19-11um
Spectral range 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um		 0.19-2.1um, 2.94um,
9-11um
Maximum power density** 5kW/cm² @200W 5kW/cm² @200W 5kW/cm² @200W 5kW/cm² @200W
Cooling Air cooling Air cooling Air cooling Air cooling
Weight 1.5kg 3.0kg 1.5kg 3.0kg
Dimension 90x90x70mm 122x122x118mm 122x122x118mm 122x122x118mm
Connector length 2.5m 2.5m 2.5m 2.5m
  • * The detector is centrally illuminated at 50% of the effective surface.
  • ** The damage threshold also depends on the power level.

3. Kw Level Water-cooled Laser Power Meter

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 3

Model number SHY-W10-HP-25 SHY-W20-HP-25
Maximum average power 1000W 2000W
Minimum power 10W 20W
Power resolution 1W 1W
Noise Equivalent power(NEP) 200mW 1W
Energy range 200W/500W/1000W 200W/500W/2000W
Response time 10sec 10 sec
Power calibration uncertainty ±3% ±3%
Power linearity* ±2% ±2%
Aperture 25mm 25mm
Type HPB HPB
Absorption spectrum 0.19-11um 0.19-11um
Spectral range 0.19-2.1um, 2.94um, 9-11um 0.19-2.1um, 2.94um, 9-11um
Maximum power density** 500W/cm² @1000W 500W/cm² @1000W
Cooling Water cooling Water cooling
Water flow at full power
minimum
recommend
3L/min
6L/min
3L/min
6L/min
Weight 2kg 2kg
Dimension 90x90x44mm 90x90x44mm
Connector length 2.5m 2.5m
  • * The detector is centrally illuminated at 50% of the effective surface.
  • ** The damage threshold also depends on the power level.

4.Serial/USB Laser Power Meter

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 4

Model number SHY-USB-2-HP-19
SHY-RS232-2-HP-19		 SHY-USB-20-HP-25
SHY-RS232-20-HP-25		 SHY-USB-10-HP-25 SHY-RS232-10-HP-25 SHY-RS232-50-HP-25 SHY-RS232-100-HP-25
Max average power 2W 20W 10W 10W 50W 100W
Minimum power 2mW 20mW 20mW 20mW 50mW 80mW
Power resolution 100uW 1mW 100uW 100uW 10mW 20mW
Noise Equ. power 200uW 20mW 500uW 500uW 20mW 30mW
Response time 0.7sec 1.5sec 0.7sec 0.7sec 1.5 sec 1.5sec
Power calibration uncertainty ±3% ±3% ±3% ±3% ± 3% ±3%
Power linearity* ±1% ±1.5% ±1% ±1% ±1.5% ±1.5%
Aperture 25mm 25mm 25mm 25mm 25m 25m
Type HPB HPB HPB HPB HPB HPB
Absorption spectrum 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um
Spectral range 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um
Max power density** 18 KW/cm² @2W 15KW/cm² @2W 18KW/cm² @2W 18KW/cm² @2W 11KW/cm² @2W 11KW/cm² @2W
Cooling Air cooling Air cooling Air cooling Air cooling Air cooling Air cooling
Weight 0.2kg 0.2kg 0.2kg 0.2kg 0.2kg 0.2kg
Dimension 60x60x20mm 60x60x20mm 60x60x20mm 60x60x20mm 60x60x20mm 60x60x20mm
Connector length 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 5

Model number SHY-RS232-100-HP-19 SHY-USB-100-HP-19 SHY-USB-200-HP-25 SHY-RS232-200-HP-25 SHY-USB-W200-HP-25 SHY-RS232-W200-HP- 25
Max average power 100W 100W 200W 200W 200W 200W
Minimum power 50mW 50mW 0.2W 0.2W 0.2W 0.2W
Power resolution 10mW 10mW 10mW 10mW 0.1W 0.1W
Noise Equivalent power 20mW 20mW 20mW 20mW 200mW 200mW
Response time 1.8sec 1.8sec 2sec 2sec 1.8sec 1.8sec
Power calibration uncertainty ±3% ± 3% ± 3% ±3% ±3% ±3%
Power linearity* ±1% ±1.5% ±1% ±1.5% ±1% ±1%
Aperture 19mm 19 mm 25mm 25mm 25mm 25mm
Type HPB HPB HPB HPB HPB HPB
Absorption spectrum 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um
Spectral range 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um
Max power density** 11KW/cm² @40W 11KW/cm ²@40W 4KW/cm² @200W 4KW/cm² @200W 4KW/cm² @200W 4KW/cm² @200W
Cooling Air cooling Air cooling Air cooling Air cooling Water cooling Water cooling
Weight 0.70kg 0.70kg 1.5kg 1.5kg 0.2kg 0.2kg
Dimension 65x65x72mm 65x65x72mm 90x90x70mm 90x90x70mm 65x65x35mm 65x65x35mm
Connector length 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB 2.5m-RS232

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 6

Model number SHY-RS232-350-HP-25 SHY-USB-350-HP-25 SHY-USB-500-HP-25 SHY-RS232-500-HP-25 SHY-RS232-W1000-HP-25 SHY-USB-W1000-HP-25
Maximum average power 350W 350W 500W 500W 1000W 1000W
Minimum power 0.5W 0.5W 0.5W 0.5W 10W 10W
Power resolution 100mW 100mW 100mW 100mW 1W 1W
Noise Equivalent power(NEP) 200mW 200mW 200mW 200mW 200mW 200mW
Response time 2.8sec 2.8sec 5sec 5sec 10sec 10sec
  ±3% ±3% ±3% ±3% ±3% ±3%
Power linearity* ±1% ±1% ±1% ±1.5% ±2% ±2%
Aperture 25mm 25mm 25mm 25mm 25mm 25mm
Type HPB HPB HPB HPB HPB HPB
Absorption spectrum 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um
Spectral range 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um		 0.19-21um, 2.94um,
9-11um
Maximum power density** 4kW/cm2 @200W 4kW/cm2 @200W 3kW/cm2 @500W 3kW/cm2 @500W 500W/cm2 @1000W 500W/cm2 @1000W
Cooling Air cooling Air cooling Air cooling Air cooling Water cooling Water cooling
Weight 2kg 2kg 2kg 2kg 2kg 2kg
Dimension, mm 122x122x118 122x122x118 122x122x118 122x122x118 90x90x44 90x90x44
Connector length 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 2.5m-USB/
1.5m-RS232		 1.5m-USB 1.5m-RS232
  • * The detector is centrally illuminated at 50% of the effective surface.
  • ** The damage threshold also depends on the power level.

5. High Sensitivity Laser Power Meter

High sensitivity series laser power meters have many advantages like affordable, high precision, suitable for FPC cutting, drilling machine online measurement, high precision marking, solar cell equipment (scratching/ablation/back passivation/punching/etching/sintering, etc.).

Model number SHY-RS232-12-HS-18 SHY-USB-12-HS-18
Maximum average power 12W 12W
Minimum power 1mW 1mW
Power resolution 0.1mW 0.1mW
Noise Equivalent power(NEP) 50uW 50uW
Response time 3sec 3sec
Power calibration uncertainty ±3% ±3%
Power linearity* ±1.5% ±1.5%
Aperture 18mm 18mm
Type HS HS
Absorption spectrum 0.19-11um 0.19- 11um
Spectral range 0.19-2.1um, 2.94um, 8-11um 0.19-2.1um,2.94um,8-11um
Maximum power density** 25kW/cm2 25kW/cm2
Cooling Air cooling Air cooling
Weight 0.20kg 0.20kg
Dimension 60x60x20mm 60x60x20mm
Connector length 1.5m-RS232 2.5m-USB
  • * The detector is centrally illuminated at 50% of the effective surface.
  • ** The damage threshold also depends on the power level.

6.SHY Series Laser Energy Meter

Low Power / Medium Power / High Sensitivity Laser Power Energy Meter 7

Model number SHY-PE10-HP-0.6J SHY-PE10-HP-25-3J SHY-PE10-HP-19 SHY-PE50-HP-19 SHY-PE200-HP-25 SHY-PE500-HP-25
Maximum average power 10W 10W 10W 50W 200W 500W
Minimum power 20mW 20mW 20mW 50mW 0.1W 0.5W
Power resolution 0.001W 0.001W 0.001 W 0.01 W 0.01W 0.1W
Noise Equivalent power(NEP) 1mW 1mW 1 mW 20mW 300mW 500mW
Energy range 50mJ-200J 100mJ-200J 50mJ-200J 50mJ-200J 100mJ-300J 100mJ-300J
Energy scale 0.6J/30J/200J 3J/30J/200J     3J/30J/300J 3J/30J/300J
Energy resolution 1mJ 1mJ 1mJ 1mJ 1mJ 1mJ
Power calibration uncertainty* ±3% ±3% ±3% ±3% ±3% ±3%
Aperture 25mm 25mm 19mm 19mm 25mm 25mm
Type HPB HPB HPB HPB HPB HPB
Absorption spectrum 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um 0.19-11um
Calibration spectral range 0.19-2.1um,
2.94um,
9-11um		 0.19-2.1um,
2.94um,
9-11um		 0.19-2.1um,
2.94um,
9-11um		 0.19-2.1um,
2.94um,
9-11um		 0.19-2.1um,
2.94um,
9-11um		 0.19-2.1um,
2.94um,
9-11um
Maximum power density** 15kW/cm2 @10 W 15kW/cm2 @10 W 15kW/cm2 @10W 11kW/cm2 @40 W 15kW/cm2 @10 W 15kW/cm2 @10 W
Cooling Air cooling Air cooling Air cooling Air cooling Air cooling Air cooling
Weight 0.2kg 0.2 kg 1.0kg 1.5kg 2kg 2kg
Dimension 60x60x20mm 60x60x20mm 65x65x35mm 65x65x35mm 90x90x70mm 122x122x118mm
Connector length     2.5m 2.5m
  • * The detector is centrally illuminated at 50% of the effective surface.
  • ** The damage threshold also depends on the power level.

Tag:

Thermal Cameras,

Laser Rangefinder,

Laser Power Meter Laser Energy Meter

Contact Details
Wuhan Sintec Optronics Co., Ltd,

Contact Person: Steven

Tel: +86 15671598018

Fax: 86-027-51858989

Send your inquiry directly to us (0 / 3000)

About

Laser Cutting Machine

3D Robotic Cutting Machine for Aluminum Alloy Frames, Baby Carriage Frames, Electric Vehicle Frames

Engineering Plastic Cutting, Automotive Interior Plastic Parts and Other Composite Material Cutting, 3D Cutting Machine

OEM ODM Raycus MAX CW Fiber Laser Cutter Machine 1000W 2000W

Laser Welding Machine

Handheld 3 In 1 Fiber Laser Welding Cleaning Cutting Machine 1500W 2000W 3000W

3 IN 1 Multifunction Fiber Laser Welding Cutting Cleaning Machine Handheld 2KW

1500W 3 in 1 Laser Welder Cleaner Cutter Handheld for Metal

LEAVE MESSAGE

Privacy Policy | China Good Quality Laser Cutting Machine Supplier. © 2023 - 2024 chinalasermart.com. All Rights Reserved.
