75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser

75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser
75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser 75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser 75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser 75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser 75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser

Large Image :  75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser

Product Details:
Brand Name: Sintec Optronics
Model Number: STR Series
Payment & Shipping Terms:
Delivery Time: Stock
Payment Terms: T/T via bank
Contact Now

75W To 1500W Ultrafast Lasers and Fiber Lasers High Power QCW Fiber Laser

Description
Highlight:

Lasers and Fiber Lasers

,

Ultrafast Lasers and Fiber Lasers

,

Fiber Laser

75W to 1500W High Power QCW Fiber Lasers



The Quasi-Continuous Fiber Laser Series ranges from 75W to 600W, with higher electro-optical conversion efficiency, better optical quality and lower maintenance cost. This series product is a perfect alternative of existing light-pumped YAG laser and is an ideal choice for spot welding, seam welding, boring and other industrial applications needing wide pulse and high peak due to its persified compatibility and the convenience for most YAG systems to use it with simple transformation.

Features:

  • High electro-optical conversion efficiency > 30%

  • Two work modes: continuous and pulse

  • Extremely stable output performance

  • Excellent light beam quality

  • Optional QCS / QBH output connector and output length

Technical specifications:

Model STR-QCW150/1500 STR-QCW300/3000 STR-QCW450/4500 STR-QCW600/6000
Operation mode CW/Modulation CW/Modulation CW/Modulation CW/Modulation
Average power(CW), (W) 250 500 750 800
Average power(Pulse), (W) 150 300 450 600
Maximum output power, (W) 1500 3000 4500 6000
Maximum pulse energy,(J) 15 30 45 60
Wavelength (nm) 1080±5 1080±5 1080±5 1080±5
Repetition rate (Hz) 0-5000 0-5000 0-5000 0-5000
Pulse width (ms) 0.05-50 0.05-50 0.05-50 0.05-50
Output power stability <3% <3% <3% <3%
Red laser Yes Yes Yes Yes
Beam delivery connector QBH QBH QBH QBH
BBP (mrad) 0.4, 2, 5 5, 10 5, 10 5, 10
Power supply 200-240 340-420 340-420 340-420
Control mode RS232/AD RS232/AD RS232/AD RS232/AD
Power output range (%) 10-100 10-100 10-100 10-100
Power consumption (W) 1000 2000 3000 3500
Size (mm) 485x240x680 650x890x1000 650x1000x1450 650x1000x1450
Weight (kg) <50 <150 <200 <250
Cooling Air Water Water Water
Operation temperature (°C) 10-­40 10-­40 10-­40 10-­40
